Continuous Passive Motion (CPM) Machine

H&R Healthcare » Continuous Passive Motion (CPM) Machine » Continuous Passive Motion (CPM) Machine

Designed to provide anatomical motion for knee patients that need Continuous Passive Motion (CPM) from pediatric to adult, including athletic and bariatric patients.

Features:

Ultra wide carriage – 11 inches from center of carriage

  • Independent delay time
  • Selectable scrolling
  • Patient lockout (“Lock-up”) feature
  • Universal left/right design
  • On board power supply along with surface mount electronics to maximize reliability
  • Brighter backlit display for easier reading
  • Force reversal safety feature to allow therapist to safely set amount of passive force without causing unnecessary pain or damage to the involved knee.
  • Lightweight design – 27 lbs.



Specification Description
Knee Flexion: 120°
Knee Extension: -10°
Speed: 30° - 150°/minute
Pauses: 0 - 30 seconds
Force Reversal: 35 - 75 lb (16 - 34 kg)
Maximum Patient Weight: 350 lb (159 kg)
CalfLengthRange(knee joint to sole of foot): 10" - 23.5" (25.4 - 59.7 cm)
ThighLengthRange: 12" - 19" (30.5 - 48.3 cm)
Mains Power: 100 - 240 V, 50/60 Hz
Unit Weight: 27 lb (12 kg)
Shipping Weight: 41 lb (18.6 kg)
Length: 37" (94 cm)
Electrical Safety Class: Class 1, Type B
Safety Tests: UL/IEC/EN 60601-1, IEC/EN 60601-1-2:2001
